This is the result if you use a translation app. Sorry cant do it more fast now:
Problems Lokasil operating jacks Porsche Boxster 2, 5L-2, 7L-3, 2L-Carrera 996 3, 4L-3, 6 L, as well as Carrera 997 3.6-3, 8 L
Description of the problem of the original Lokasil cylinder coated careers, experiencing the first water-cooled engines, from my point of view and 40-year-old Porsche Porsche. The engines we have repaired again during our activity approximately 380 pieces, about 70% have problems with the soft aluminum Lokasil cylinder raceways, the motor housing. Defective engines of this type was partly just read 21,000 km, the vehicles were information first-hand, the credible km...
Despite again exchanged cylinder raceways or motor housing, these engines "again not long life expectation." had to soft aluminium Lokasil Everything has brought nothing to attempts with only sliding coating of the piston. Guarantees of service type-setter often already expired customers after relatively short life his engine "again" the loser. This old generation of cases are no longer installed in the new Porsche models. Why probably? Check the forums, what problems do these first water-cooled models. Many models available 996/997 or Boxster engine already 3 or 4.
While motor housing hardly worn be used this way, get around as good as no longer given piston distance of 0.04 mm average.
Our long experience has shown (painful and very expensive), already with a higher piston distance of 0,02 to 0, 03 mm engine knock making noise the piston tilt, the sharp edges of the piston rings this race very soft damage Lokasil cylinder and it comes other piston eater, scratches and cracks in the cylinders after a short time. In most cases, bearing housing, which runs the camshafts in the cylinder head, crankshaft and bearings so then through the resulting chips are the crank. New price of crankshaft with over 6,400 euros housings, cylinder heads 4,700 euros.
Such repair is then hardly any cost to make relevant. You will need a replacement engine factory. The cost is around 18,000 euros. Has but again only the fragile aluminum Lokasil cylinder...!
We know vehicle owners from 996, Boxster, the 4th replacement engine in the vehicle have been.
Even under the guidance and support provided by the manufacturer, piston Schmid, whose technical info and advice could we really stable and long-lasting engines with aluminium Lokasil cylinder worked.
(We're talking 250,000 km and more, just as the first air-cooled engines, which also very long, steel cylinders in aluminium, much higher turned coat, that today we again use) These were engines that Porsche had won at all racetracks in the world. Of course, this old proven processing for the 987 is very expensive but also very durable 997 engines for us, 996, the price is only possible via the large quantities that we produce now.)
Aluminium Lokasil not so as expected keep the original ENGINES of the first series. Of 10 experienced Porsche companies make no water-cooled problem more 8 motors, we were also to give up. 3 warranty 2 years that no one has revised 10 Lokasil engines. Then we have the Council steel cylinder, as in racing to try.
Exactly what Porsche successfully cylinder jacks used has built for many years without any problems, air-cooled engines on steel!
(Admittedly very complex and)
expensive for series production)
Ok. We, the last test thought (very expensive). After several attempts under the guidance of "We shot" multiple engines to the test again, until we had the correct cylinder alloy, which determines proper film play coating and the right piston, etc and also tried. The result of the last 146 engines built no backscatter! This was the BREAKTHROUGH for us then finally, finally!
According to many, ceramics trying better stopped, as anything other than nickel, chrome. We're talking durability not by short-term high extreme loads the first 20,000 KM here used in racing, but then renewed after each use.
IMPORTANT INFORMATION:
Cylinder coatings, there are hundreds, also nickel O. ceramic, these coatings are approximately 0.05 mm up to 0.10 mm and hardly the career of cylinder cylinder against high pressures to strengthen aluminum and very often occur cylinders as they only on the first water these recurring cracks in alloy-cooled engines. Our steel, the Zylinder(Legierung), which is tried and tested for years at the top of the cylinder pressure range (shooting). 7 mm thick! about 700 to 1,400 times thicker than one can cope with thin, only coated aluminum cylinder and thus experience much better high pressure. AND this is important when the Porsche 986, 987, 996, 997, etc motor.
I tell you, if you have worked 15 years in the Porsche, 15 years have made race you year cooled motors start over again in the 30th with the extremely dangerous water!
We use only modified intermediate shaft, there are always problems to other intermediate shafts as the original intermediate shaft with the.
Our intermediate shafts are much more durable.
In addition, we've changed the oil pump!
Supplement for oil pans extension!
(In our opinion that is just as important as the other engine improvements, if not even more important!)
We had the result with the last 146 outdated Motors no motor more intermediate shafts or piston damage. After consultation with our customers even after the performance of over 200,000 km.
Therefore has management decided to give guarantee everything is lubricated by oil circulation now 3 years and 35,000 KM! This is not the statutory warranty.
We offer you a completely new Ausgebuchstes 3, 4L, 3. 6 L or. 3, 8 L also exchanged Boxster engine case with revised cylinder head, crankshaft, smooth coated piston with our guaranteed fresh polished new dimension of the camshafts, cylinder engine block completely together, after each request on request.
"New cylinder Groove" type GT3. These liners simply have no more problems as its predecessor models, the technology and experience.
& Gt; Finally, NO soft aluminium
LOKASIL cylinder & lt;
But steel cylinder as the racing version!
